Rational Deployment of CSP Heuristics

Constraint Satisfaction

A constraint satisfaction problem (CSP) is defined by:

variables $\mathcal{X}=\{X_1, X_2, ...\}$,
constraints $\mathcal{C}=\{C_1, C_2, ...\}$.

Each variable $X_i$ has a non-empty domain $D_i$ of possible values.
Each constraint $C_i$ involves some subset of the variables—the scope of the constraint—and specifies the allowable combinations of values for that subset.
An assignment that does not violate any constraints is called consistent (or solution).

Rational Metareasoning

A problem-solving agent can perform base-level actions from a known set $\{A_i\}$.
Before committing to an action, the agent may perform a sequence of meta-level deliberation actions from a set $\{S_j\}$.
At any given time there is a base-level action $A_\alpha$ that maximizes the agent's expected utility.

The net VOI $V(S_j)$ of action $S_j$ is the intrinsic VOI $\Lambda_j$ less the cost of $S_j$: \[V(S_j)=\Lambda(S_j)-C(S_j)\]

The intrinsic VOI $\Lambda(S_j)$ is the expected difference between the intrinsic expected utilities of the new and the old selected base-level action, computed after the meta-level action is taken: \[\Lambda(S_j)=\mathbb{E}\left(\mathbb{E}(U(A_\alpha^j))-\mathbb{E}(U(A_\alpha))\right)\]

$S_{j_{\max}}$ that maximizes the net VOI is performed: $j_{\max} = \arg\max_jV(S_j)$,
if $V(S_{j_{\max}})>0$.
Otherwise, $A_\alpha$ is performed.

Acknowledgments

IMG4 Consortium under the MAGNET program of the Israeli Ministry of Trade and Industry
Israel Science Foundation grant 305/09
Lynne and William Frankel Center for Computer Sciences
Paul Ivanier Center for Robotics Research and Production Management

Experiments

Benchmarks

CSP benchmarks from CSP Solver Competition 2005 were used. 14 benchmarks were solved for $\gamma=0$ and the exponential range $\gamma \in \{10^{-7},$ $10^{-6},$ $...,$ $1\}$, as well as with the minimum-conflicts heuristic and the pAC heuristic.

The maximum improvement is achieved when the solution count is estimated only in a small fraction of occasions selected using rational metareasoning.

Random instances

Based on the results on benchmarks, we chose $\gamma=10^{-3}$, and applied it to two sets of 100 problem instances. Exhaustive deployment, rational deployment, the minimum conflicts heuristic, and the pAC heuristic were compared.

The value of $\gamma$ chosen based on a small set of hard instances gave good results on a set of instances with different parameters and of varying hardness.

Generalized Sudoku

Real-world problem instances often have much more structure than random instances generated according to Model RB.
We repeated the experiments on randomly generated Generalized Sudoku instances— a highly structured domain.
Relative performance on Generalized Sudoku was similar to Model RB.

Overview

Heuristics are crucial tools in decreasing search effort in various areas of AI.
A heuristic must provide useful information to the search algorithm, and be efficient to compute.
Overhead of some well-known heuristics may outweigh the gain.
Such heuristics should be deployed selectively, based on principles of rational metareasoning.

Case Study

CSP backtracking search algorithms typically employ variable-ordering and value-ordering heuristics.
Many value ordering heuristics are computationally heavy, e.g. heuristics based on solution count estimates.
Principles of rational metareasoning can be applied to decide when to deploy the heuristics.

Value Ordering

Value ordering heuristics provide information about:

$T_i$—the expected time to find a solution containing an assignment $X_k=y_{ki};$
$p_i$—the probability that there is no solution consistent with $X_k=y_{ki}$.

The expected remaining search time in the subtree under $X_k$ for ordering $\omega$ is given by: \[T^{s|\omega}=T_{\omega(1)}+\sum_{i=2}^{|D_k|}T_{\omega(i)}\prod_{j=1}^{i-1}p_{\omega(j)}\]

The current optimal base-level action is picking the $\omega $ which optimizes $T^{s|\omega}$. $T^{s|\omega}$ is minimal if the values are sorted by increasing order of $\frac {T_i} {1-p_i}$.
The intrinsic VOI $\Lambda_i$ of estimating $T_i, p_i$ for the $i$th assignment is the expected decrease in the expected search time: $\Lambda_i=\mathbb{E}\left[T^{s|\omega_-}-T^{s|\omega_{+i}}\right]$.
Computing new estimates (with overhead $T^c$) for values $T_i, p_i$ is beneficial just when the net VOI is positive: $V_i=\Lambda_i-T^c$.

Main Results

Rational Value Ordering

The intrinsic VOI $\Lambda_i$ of invoking the heuristic can be approximated as: \[\Lambda_i\approx \mathbb{E}\left[(T_1-T_i)|D_k|\,\Big|\; T_i < T_1 \right]\]

VOI of Solution Count Estimates

The net VOI $V$ of estimating a solution count can be approximated as: \[V \propto |D_k|e^{-\nu}\sum_{n=n_\mathrm{max}}^\infty \! \! \left( \frac 1 {n_\mathrm{max}} - \frac 1 n\right) \frac {\nu^n} {n!}-\gamma\] where the constant $\gamma$ depends on the search algorithm and the heuristic, rather than on the CSP instance, and can be learned offline. The infinite sum $\sum_{n=n_\mathrm{max}}^\infty \! \! \left( \frac 1 {n_\mathrm{max}} - \frac 1 n\right) \frac {\nu^n} {n!}$ is rapidly converging and can be computed efficiently.

Conclusions

This work suggests a model for adaptive deployment of value ordering heuristics in algorithms for constraint satisfaction problems.
As a case study, the model was applied to a value-ordering heuristic based on solution count estimates, and a steady improvement was achieved compared to always computing the estimates.
For many problem instances the optimum performance is achieved when solution counts are estimated only in a small number of search states.

Future Work

http://www.offtopia.net/ijcai-2011-csp-poster/

Generalization of the VOI to deploy different types of heuristics for CSP.
Explicit evaluation of the quality of the distribution model, coupled with a better candidate model of the distribution.
Application to search in other domains, especially to heuristics for planning; in particular, examining whether the meta-reasoning scheme can improve reasoning over deployment based solely on learning.
